Galaxies

As for the Latest page, the most recent images are at the top of the page.

I was away from home most of the Summer (see the Eclipse 2010 trip), and the Autumn weather was disappointing. This small but beautiful galaxy, magnitude 10.2 NGC 7217 in Pegasus was a real challenge. I tackled it on three separate nights, but seeing conditions almost defeated me, and the only really worthwhile luminance data was 4 x 20 minute frames from the early hours of 30th August 2010. But it proved just enough to tease out the fine detail . RGB was only 3 each at 5 minutes binned 2x2. ST-10XME with AO-8 on 12" LX200ACF at f10.

Full size

Well, the Milky Way is a galaxy, as are the Magellanic clouds! So I feel it only right to include them here, these being the only shots I have of the Southern sections of our home galaxy.

During my extended holiday including viewing the 2010 Solar Eclipse in the South Pacific, it was always my intention to photograph the Southern Milky Way, not only in wide field, but also with some more close up images using my 400 mm Canon lens. I had no opportunity during our stay on Tahiti and Moorea, and for most of the following two weeks on New Zealand the Moon was intrusive. Towards the end of that stay I obtained this image from a dark camp site (we were in a camper van) at Fairlie in South Island. Lots of trees unfortunately, and the Moon rose before I could go for close ups. But good views of the Clouds of Magellan, the Southern Cross, the Coalsack and Carina nebulae. Composite of 5 x 5 minute exposures at ISO800, Canon 350D and Tamron 17-50 lens at 17 mm and f5.6 Full Size

Later in the holiday we stayed with relations near Launceston, Tasmania. With four nights there I expected to be able to enjoy the night sky - New Moon and a dark site. But it was not to be - cloud and rain alas. The only remaining opportunity was from the next stop with relations on the Gold Coast near Brisbane. But there was light pollution and a brightening Moon. Nevertheless I obtained this pic of the heart of the Milky Way - a couple of constellation figures in for identification. Canon 350D, 5 x 5 minute sub frames at ISO 800, Tamron lens at 17 mm. Constellation figures also on the medium size image (click on thumbnail).

Full size.

All the 17 mm shots were taken unguided on my EQ3-2 mount - the mount tracking was accurate enough at the short focal length, and I had a good Polar alignment. So to finish off, I zoomed the lens up to 50 mm, just for a try. And indeed the unguided tracking was also good enough at that focal length. This shows the Southern Cross and Coalsack area. So although I had a guide camera with me, I never used it. Full size.

I guess I'll have to return South some time. Maybe in 2012 for the Transit of Venus !

NGC 4438 (the larger one) and NGC 4435 , 'The Eyes' in Virgo. The extreme distortions of 4438 are probably due to the proximity of 4435.

Numerous background galaxies in this image, taken over two nights, 7th and 9th April 2010. Luminance 20 x 10 minutes, RGB each 7 x 5 minutes binned 2x2. ST-10XME with AO-8 and Astronomik filters on 12" LX200ACF at f7.

Full size

Barred spiral Canes Venatici galaxy Messier 106. The small galaxy in the corner is NGC 4248. March 10th and 21st 2010. Luminance 24 x 10 minutes, RGB each 7 x 5 minutes binned 2x2. ST-10XME with AO-8 on 12" LX200ACF.

NGC 3628 Disturbed Galaxy in Leo. February and March 2010. Luminance 44 x 10 minutes, RGB each 6 x 5 minutes binned 2x2. ST10XME with AO-8 on 12" LX200R.

This image appeared in the August 2010 issue of Sky at Night magazine.

The 'Whale' (NGC 4631) and 'Hockey Stick' (NGC 4656) galaxies in Canes Venatici. 28th March 2009 (from Kielder, Northumberland).

Luminance 18 x 10 minutes, RGB each 5 x 5 minutes binned 2x2. ST10XME, AO-8, Astrodon filters, Meade Series 5000 127 refractor.

Numerous tiny background galaxies visible in the Full size image.

This image appeared in the September 2009 issue of Sky at Night magazine



M94 galaxy in Canes Venatici. 20th March 2009.

13 x 10 minutes Luminance, RGB each 5 x 4 minutes binned 2x2. ST-!0XME and AO-8 on 12" LX200ACF at f10. Full size

The background when stretched shows the unusual and interesting outer halo.

NGC 891, edge on galaxy in Andromeda. 25th, 26th and 28th October 2008.

Luminance 38 x 10 minutes, RGB each 8 x 3 minutes, binned 2x2. ST10XME and AO-8 on 12" LX200ACF OTA at f10, Astrodon filters

This image was published as Picture of the Month in the April 2009 edition of Sky at Night magazine.

NGC 7479 barred spiral galaxy in Pegasus. 24th and 28th October 2008.

SBIG ST10XME with AO-8, Astrodon filters, 12" LX200ACF OTA at f10, Luminance 8 + 8 x 10 minute subs, RGB each 8 x 3 minutes binned 2x2

Messier 31, the Great Galaxy in Andromeda. 2nd August 2008 at Les Granges, France.

SBIG ST10XME with ZS66 and 0.8 reducer, Luminance 5 x 5 minutes, RGB each 5 x 2 minutes.

Markarian's Chain in Virgo. 4th April 2008 at Kielder.

SBIG ST-4000XCM one-shot colour camera (belonging to a friend), TMB105 with f7 reducer. 7 x 10 minutes.

NGC 2685 - the Helix or Spindle galaxy. Peculiar polar ring galaxy in Ursa Major. Also classified as Arp 336. Several imaging attempts during March 2008.



SBIG ST8XME and 12" LX200 ACF at f10 (cropped from full frame). Luminance 22 x 15 minutes, RGB each 5 x 5 minutes binned 2x2

This image was published in the May 2008 issue of Practical Astronomer

Messier 96 spiral galaxy in Leo. 12th February 2008.

SBIG ST-8XME, 12" LX200 ACF at f10, AO-8. Luminance 1 x 8 min + 12 x 10 mins RGB each 8 x 3 mins binned 2x2, Astrodon filters.

NGC5394/5 (Arp 84) interacting galaxies in Canes Venatici. 11th and 12th February 2008.

ST-8 on 12" LX200 ACF at f10, guided using AO-8. Luminance 13 x 10 minutes, RGB each 6 x 3 minutes binned 2x2.

This image was published in the April 2008 issue of Astronomy Now

NGC 2403 spiral galaxy in Camelopardalis. 11th February 2008.

ST-8 on 12" LX200 ACF at f7. Luminance 15 x 7 minutes, RGB each 5 x 3 minutes binned 2x2. North is up.

NGC 3718 in Ursa Major. SBIG ST-8 and AP 0.7 reducer on the 12" LX200R, with SBIG AO-8 'adaptive optics' unit. 11th January 2008.

Luminance10 x 10 minutes, RGB each 4 x 4 minutes binned 2x2.

NGC 6946, spiral galaxy in Cepheus. August 23rd 2007. The supernova of 2004 has now faded - captured then with my MX716 camera.

SBIG ST8XME with LX200R at f7, Luminance 8 x 5 minutes, RGB each 4 x 5 minutes.

NGC 5128, Centaurus A galaxy. La Palma, June 10th 2007. Artemis 285 and Meade 10" LXD55 Schmidt-Newtonian telescope (f4). Luminance 7 x 3 minutes, RGB each 5 x 90 secs binned 2x2.

Although it looks as though this image is vignetted, it ain't! See this image from the ESO. But because I only had limited data, mine is rather 'noisy' in comparison! Included here although not a particularly good image, because never possible from the UK!

Barred spiral galaxy, NGC 4725 in Coma Berenices. 20th March 2007.

This galaxy is particularly unusual in having only one spiral arm. The small neighbouring galaxy is NGC 4712. Artemis 285 and Mirage 8 at f6.3. Luminance 11 x 6 minutes, RGB each 4 x 5 minutes.

12th. March 2007. NGC 4490 and its smaller companion NGC 4485 in Canes Venatici show the gross disturbances occasioned by the close encounter. I feel that the larger galaxy has the appearance of a water flea about to devour a smaller morsel! I would like to name it the Water Flea Galaxy!

Artemis 285, Mirage 8 at f6.3. Luminance 12 x 6 minutes, RGB each 4 x 6 minutes.

Messier 74, spiral galaxy in Pisces. 23rd. September 2006.

Artemis 285 and Mirage 8 at f6.3 Luminance 22 x 5 minutes, RGB each 3 x 3 minute binned 2x2

This image is the Astronomy Now M74 Messier Challenge winner, and was featured in the November 2006 issue. It appeared again in the May 2010 issue.

Messier 51 spiral galaxy in Canes Venatici. 4th and 6th April 2006

Art285, Mirage at f 6.3, Luminance 9 frames x 5 minutes, RGB each 3 frames x 3 minutes binned 2x2, plus Hydrogen Alpha 6 x 5 minutes binned 2x2

Messier 82, disturbed galaxy in Ursa Major. January 29th 2006.

Artemis with Mirage at f6.3. Luminance 12 x 4 minute, RGB each 3 x 2 min binned 2x2 plus extra red from 12 x 4 minute H-alpha

Hickson 44 (Arp316) Group of galaxies NGCs 3193, 3187 (barred), 3190 and near the bottom, 3185, in Leo. 13th. December 2005. Art 285 and Mirage 8 at f6.3 Luminance 9 x 4 minutes, RGB each 3 x 2 minutes binned 2x2

M33, the 'Pinwheel' galaxy in Triangulum. 6th December 2005. Artemis 285, TMB refractor with 0.63 reducer. Luminance 10 x 6 minutes, RGB each 3 x 6 minutes.

NGC4565 edge on galaxy in Coma Berenices. 10th. May 2005. Artemis 285 and Mirage 8 at f6.3

This image was published in the September 2005 issue of Astronomy Now

M64 - 'Blackeye' galaxy in Coma Berenices. 2nd. April 2005. Artemis 285 and Mirage 8 at f6.3 L 15 x 2 min, RGB each 2 min binned 2x2.

NGC7331 and the 'Deer Lick' group of galaxies in Pegasus. 26 August 2004. MX716, Mirage 8 at f6, L 7 x 5 min, RGB 1 x 5 min each.
